What kind of encoder is MD520-PG-S1 PG card?
MD520-PG-S1 is a PG card that decodes sine and cosine encoders, and is used in conjunction with a frequency converter to achieve motor speed measurement and speed closed-loop control
Control system, position closed-loop control, and encoder frequency division output.
This manual introduces the technical specifications, dimensions, installation, wiring, etc. of the MD520-PG-S1 expansion card. For details, please click on the download link
Table 1-1 Technical specifications of sine cosine encoder
Project Technical Specifications
Encoder 5V power supply 5V/300mA
Differential voltage 06Vpp~1.2Vpp
1.0Vpp (Typ)
Common mode voltage 3V (Max)
Bandwidth 300kHz
describe
Vpp: Peak to peak value, which is the peak value of the output signal of the sine cosine encoder, and is the signal range that the PG card can accept
Surrounding.
Typ: Typical value, i.e. universal value, such as 1.0Vpp.
Max: Maximum value, there is no minimum value for common mode voltage, only the maximum value.
